Finally, our 6.5 Creed Battle Rifles are ready to ship. Based off of the Aero M5 (DPMS High) platform combining all of the features you would expect from a FS Pro upper. 18" Hanson .875"barrel that is perfectly gassed and extremely accurate while still balancing weight. Finishing the build we have Aero handguards, NIB BCGs, Aero Breach CHs, and all of the quality assembly processes and unlimited lifetime warranty (first free rebarrel as well).
*Any Muzzle Device Available Upon Request At Dealer Cost (No Markup)
The Basics
18" Hanson 416R SS Black Nitrided Barrel , Atlas R-One 15" Mlock Handguard, NIB .308/6.5c BCG, Aero Precision M5 Upper, & Aero Breach Charging handle
Factory Pinned Gas Block, Lapped Upper Receiver, Bedded Barrel, Every component is hand fitted and tested prior to assembly, test firing, and ultimately shipping.
The Specifics
Barrel:
Manufacturer - Ballistic Advantage
Length/Chamber - 18" 6.5 Creedmoor
Twist - 1:8
Material - 416R SS
Profile - Hanson
Gas System - Mid-Length
Finish - Black Nitride
Thread Pitch - 5/8x24
Gas Port - .056~
*Pinned Gas Block*
1st Rebarrel - FREE
Barrel nut is sequentially torqued down to 50 FT-lbs. Starting at 25, then 35, and then finally 50 FT-lbs to ensure proper mating of the threads.
Barrel is also bedded to the upper receiver with an expanding/hardening compound to ensure perfect fit and reliable accuracy.
If you legit burn out a barrel, like 10,000 -25,000 rounds, and the barrel becomes inaccurate I will rebarrel it for you for free. Good luck.
Bolt Carrier Group:
Manufacturer - Toolcraft
Bolt Material - 9310 Alloy
Carrier Material - 8620 Alloy
Gas Key Material - 4130 Alloy
Profile - DPMS
Finish - NIB
Gas Key Screws - Grade 8
Forward Assist Cuts
Mil-Spec Firing Pin (Hard Chrome Coated)
Viton O-Ring Enhanced Extraction
Handguard:
Manufacturer - Aero Precision
Model - S-One
Lengths - 15"
Material - 6061 T6 Aluminum
Finish - Hard Coat Black Anodization
Mounting Platform - Mlock
Barrel Nut - Steel
Barrel nut torqued to 50 FT-lbs
Taper Lock torqued to 30 IN-lbs with blue Loctite
We apply a Permatex Anti-Seize solution to the receiver extension before installing the barrel nut to ensure they do not lock up over many years of hard use.
Upper Receiver:
Manufacturer - Aero
Style- M5 (DPMS High)
Material - 7075 T6 Aluminum
Machined from Forged Aluminum
Finish - Type 3 Hardcoat Anodized Black
Standard Dust Cover
M4 Feed Ramps
T-Marked, if you care...
Uppers are lapped to ensure the truest connection between the upper and barrel for maximum possible accuracy.
Charging Handle:
Manufacturer - Aero Precision
Type - Mil-Spec
Material - 7075 T6 Aluminum
Finish - Type 3 Hardcoat Anodized
Gas Block:
Manufacturer - Ballistic Advantage
Material - 4140 Steel
Style - Low Profile
Size - .875"
Attachment Method - 2x Set Screws + Steel Roll Pin
Set screws are torqued to 30 IN-lbs and have High-Temp Permatex 272 threadlocker applied for extra security.
*Please contact me before attempting removal of the Gas Block. These are not meant to be tampered with.
Gas Tube:
Length - Mid Length
Material - Stainless Steel
*** Any flash hider/ muzzle brake on the market can be substituted at dealer cost on your upper ***
Flash Hider:
Type - A2
Manufacturer - KAK
Thread Pitch - 5/8x24
Caliber - .30/7.62mm
The Build Process:
Every upper is assembled by me, one at a time. Every piece is hand fit, barrels to the uppers, gas blocks to the barrels, gas tubes to gas blocks, handguards, roll pins, You get the picture. What all that means is that you get an upper that you can depend on and will hold up to years of hard use.
18" 6.5 Creedmoor Battle Rifle Pro Complete Upper - Hanson .875" Barrel
These are assembled by me by hand as well as transported back and forth from the range from test firing. Becuase of the handling of the uppers there will be some very minor cosmetic blemishes. If you are looking for a showroom finish, please look elsewhere. I expect my uppers to be used harshly and to handle the abuse. Any issues with function will be immediately addressed and remedied to the satasfaction of the customer.
